Description
1CH 1A Flush-mounted Dimming Actuator (EU) is a smart dimming executive module installed in the wall box of the European standard panel. The actuator has the characteristics of exquisite structure and rich circuits.
1CH 1A Flush-mounted Dimming Actuator (EU)
1CH 1A Flush-mounted Dimming Actuator (EU) is a smart dimming executive module installed in the wall box of the European standard panel. The actuator has the characteristics of exquisite structure and rich circuits.
Đặc trưng
- With 1CH 1A MOSFET trailing/leading edge dimming control channel
- With 4 dry contact switch signal input channels, 4 LED switch signal output channels
- With programming button and programming indicator, short press the programming button to control all dimming channels on/off
Thông số
Basic Parameters
Working voltage ：15-28V DC
Working current ：48mA/24V DC
Dimming channel ：1CH, 1A/CH (AC100-240V, 50/60Hz)
Dry contact：4CH dry contact input
LED：4CH LED output, 12mA/CH
Dimming mode：MOSFET trailing/leading edge dimming
Communication：HDL Buspro
Cable diameter of Buspro terminal：0.6-0.8mm
External Environment
Working temperature ：-5℃~45℃
Working relative humidity ：≤90%
Storage temperature ：-20℃~60℃
Storage relative humidity ：≤93%
Specifications
Dimensions：46.8mm×46.8mm×23mm
Net weight：39g
Housing material：Flame retardant PC
Installation：Wall box
Protection rating (Compliant with EN 60529) ：IP20
